Canon imagePROGRAF TA-30

Canon
Canon imagePROGRAF TA-30

imagePROGRAF TA-30

Bring your printing in house with the imagePROGRAF TA-30 large format printer. With uncompromising quality, this multipurpose 36″ printer, offers a cost-efficient, easy-to-use solution built to stimulate workflow and productivity for small businesses and first-time large format print users. The TA Series ships with free poster/marketing creation software and a Print Plug-in for Microsoft Office.

Call us today at (602)224-9971 so we can help you find the right plotter to fit your needs

Print More Out of the Box



The TA Series ship with 164% more ink than the comparable HP and 157% more ink than the comparable Epson currently offer. 330ml ink in total – over a $250 value!



Low Cost of Operation

Economy Print Mode (Fast (Q5)) allows for up to 40% less ink to be used during printing than
standard mode Q3

– helping to lower your operation costs.

Unparalleled Speed

Print 113 24 x 36 posters per hour1. That’s 43 more posters than the HP T130 can print!*


Print Outdoor Poster

Unlike the HP DesignJet printers*, the TA Series use pigment ink to produce weather-resistant posters.



The Perfect Print

With Canon’s advanced Air Feeding System, paper is kept flat during printing – helping to make consistent prints every time!


Security Feature

The TA Series large-format printers come equipped with several security
features designed to help prevent leaks of confidential information:
-802.1x: Helps ensure information is secure when passing over a network by providing authentication to devices attempting to connect to the network.
-SSL/TLS: Allows sensitive information being sent via an internet connection to be sent securely for data being passed between two systems
-IPSec: Authenticates and encrypts data passed over IP networks.


Minimize Disruption in the Workplace

The TA is the quietest printer in this market.*

More Paper. More Printing

The TA has the ability to utilize long rolls (5.9″ in diameter) and a wide variety of media.

Compact Design

The TA-30’s small footprint is perfect for any office or desktop


Wi-Fi Printing

Print mobile from almost anywhere in the office or jobsite.


Nonstop Printing

The Sub-Ink Tank System lets you change empty cartridges while the
printer continues to print allowing you to use virtually all of the
available ink in the tank before having to replace it.

Virtually No Printing Limits

Print borderless on all media sizes – the competition can’t do this!* .

Printer Type5-Color 24-inch Printer
Number of NozzlesTotal: 15,360
MBK: 5,120 nozzles
C, M, Y, BK: 2,560 nozzles each
Nozzle Pitch
1,200 dpi
Non-firing nozzle detection and compensation
Print Resolution (Up to)
2,400 x 1,200 dpi (Max)
OS Compatibility

Windows® 7, 8.1, 10 (32/64bit)

Windows® Server 2008 R2, 2012, 2012 R2, 2016 (64bit)

Macintosh OS X v10.10.5-v10.12x

Standard Interfaces

USB 2.0 High-Speed 10/100/1000 Base-T/TX

Wireless LAN (IEEE 802.11 b/g/n)

Ink Droplet Size

Minimum 5 picoliter
Ink Capacity

55 ml per color

Ink Droplet Size
Pigment  Ink
Color SetPigment: Matte Black, Black, Cyan, Magenta, Yellow
Buffer Ram2 GB (Physical)
Media Width
Cut Sheet: 8- 17 (203.2mm – 431.8mm)
Roll Feed: 10 – 36 (254mm – 914.4mm)
Media Thickness
0.07-0.8mm (2.8-31.4mil)
Maximum Media Roll Diameter
5.9 (150mm)
Borderless Printing Width
8- 36(203.2mm-914.4mm)
Paper Feed Method
Roll Feed: One Roll, Top-loading, Front output
Cut Sheet: Top loading, Front output
LanguagesSGRaster, HPGL/2, HP-RTL, JPEG
Noise Level ApproxOperation: 42 dB (A)
Standby: 35 dB (A) or less
Acoustic Power: 5.8 Bels
Physical Dimensions42 (H) x 51 (W) x 35 (D)
Weight
Approximately 117 lb.(roll holder included, no inks, no print heads)
Power Source
AC-100-240V (50-60Hz)
Power Consumption
Maximum: 59W or less
Standby 3.6W or less
Power Off: .3W or less (Compliant with Executive Order)

Operating Environment

Temperature: 59°-86° F (15°-30° C)
Relative Humidity: 10-80% (No Condensation)

User-replaceable items

Print Head (PF-06)Maintenance
Cartridge (MC-31)
Ink Tanks (PFI-030)
Cutter Blade (CT-08)
Software AvailableTA Unified Printer Driver, Accounting Manager, Apple AirPrint, Canon Print Service, Device Management Console, Direct Print & Share, Free Layout Tool, Free Layout Plus, imagePROGRAF Printer Driver for Windows®/Mac®, Media Configuration Tool, Optimized Driver for AutoCAD, Canon PRINT Inkjet Selphy, Easy Photo Print Editor
  • imagePROGRAF TA-30
  • Printer Stand
  • 2″ Core Media Spool
  • US AC Power Cable
  • Tools and Screws
  • Print Head PF-06
  • Maintenance Cartridge (Installed)
  • 6 Ink Tanks (55 ml each: MBK x2, C/M/Y/BK) Ethernet Card (built-in)
  • USB 2.0 High-speed Interface
  • USB Connection Sheet
  • iWR Service Terms Leaflet
  • User Manual
  • Quick Setup Guide
  • User Software CD for Windows (Printer Driver Utilities)
  • User Registration Card
  • Media Guide
  1. Plain Paper, Fast (Q5) mode
  2. Canon products offer certain security features, yet many variables can impact the security of your devices and data. Canon does not warrant that use of its features will prevent security issues. Nothing herein should be construed as legal or regulatory advice concerning applicable laws; customers must have their own qualified counsel determine the feasibility of a solution as it relates to regulatory and statutory compliance. Some security features may impact functionality/performance; you may want to test these settings in your environment.
  3. Wireless printing requires a working network with wireless 802.11b/g or 802.11n capability. Wireless performance may vary based on terrain and distance between the printer and wireless network clients.
  4. Your server must be compatible with a WebDAV enabled cloud account, including but not limited to, Google, Carbonite or Rackspace, to take advantage of the cloud functionality. Storage capacity and any pricing thereof are based on the third-party cloud provider’s current offering, at its sole discretion. Your cloud account is subject to the third-party cloud provider’s terms and conditions.
